PMM0106 - X86 With 2x F.O
X86 BASED EMBEDDED INDUSTRIAL COMPUTER (Discountinued)
Price from USD 497.20
Key features
- Intel® Atom™ x5-Z8350 CPU
- Windows 10 lite operating system
- Meets all power substation requirements
- 2x Fiber optics
- 2x Ethernet 10/100 ports
- 2x Customizable communication ports RS485 or RS232 or RS422 or CAN bus or IO
- Built-in or add-on cards are easily customized
- Wide range of power supply options
- -40 to 85°C system operating temperature
- Different mounting system style options are applicable
- Compact, fanless design
Overview
DESCRIPTION
PMM0106 is a rugged, powerful, reliable and fanless industrial embedded computer, powered by Intel® Atom™ x5-Z8350 CPU.
Its enclosed within a durable metal chassis that has been thoroughly tested on field to withstand shock, vibration, extended temperature ranges as well as the challenging elements of the harsh environment.
With this industrial computer all field standards of power, power substation and PV requirements are met. Besides being reliable it is easily configured giving it a long-lasting life.
APPLICATION
PMM0106 is a windows 10 lite based embedded computer powered by Intel® Atom™ x5-Z8350 CPU. It is specifically designed for industrial applications where the environmental conditions are tough and unpredictable. The device contains many interfaces to cover all industrial standards giving the client increased connectivity and easy customization to fit their specific needs.
There are various industrial applications that can be performed with high efficiency and effectiveness offering intelligent and flexible solutions, PMM0106 has been optimized for the following:
- IEC 101/104 to Modbus converter
- DLMS to Modbus converter
- DNP to Modbus converter
- Schneider ION to API converter
- Multi-protocol
- Historical power meter reader
- Modbus data logger
- Multi data logger Power plant controller (PPC)
- PV optimizer
Specifications
| Computer | |
|---|---|
| CPU | Intel® Atom™ x5-Z8350 |
| DRAM | 2 GB |
| RTC CHIP | DS3231 |
| Pre-installed OS | Windows 10 lite |
| Computer Interface | |
| Ethernet | 2x ports 10/100 |
| Fiber | 2x customized fiber optics ports on ordering: | | Sc1x9 or SFP port |
| Expansion COMM Slots | 2x customizable communication slots: | PMM RS485 Module | PMM RS232 Module | PMM RS422 Module | PMM CAN Bus Module | PMM IO Module |
| USB Ports | 1x USB2.0 type A |
| Power Parameters | |
| Power Supply Options | 10-56VDC | 36-75VDC | 8-40 VAC | 25-50 VAC | 85-265VAC/ 110-300VDC |
| Power Connector | Phoenix Contact 6 pins 3.5mm |
| Physical Characteristics | |
| Housing | Metal |
| Dimensions | 5.27 x 5.27 x 1.45 inch (134 x 134 x 37 mm) |
| Mounting Options | Standard 35mm DIN Rail | Direct Panel Mounting | Front Panel Mounting | 19” rack 1U |
