PMM0202 - Billing server
Billing Server
Key features
- Allwinner H5, Quad-core 64-bit high-performance Cortex A53 CPU
- Embedded 8GB emmc hard drive
- Built to meet all Power substation requirements
- 4x customized serial ports covered all industrial standard.
- 2x Ethernet 10/100 ports
- Support 2.4GHz WIFI
- 10x direct-isolated High-speed digital inputs (24VDC)
- Many options for built-in /add-on cards
- Ubuntu Core operating system
Overview
PMM0202 is a Rugged, Powerful & Reliable industrial fanless Embedded computer powered by ALLWINNER H5 CPU. PMM0202 has metal durable chassis that is tested on field to withstand shock, vibration, extended temperature ranges and challenging elements of a harsh environment. PMM0202 meets all field standards of power, reliability, easy configuration and long-lasting life PMM0202 designed to meet all power substation and PV plants requirements
The PMM0202 is a LINUX BASED embedded computer powered by ALLWINNER H5 CPU. The PMM0202 is designed especially for industrial applications and harsh working environments. The PMM0202 has many interfaces to cover all of the industrial standards and to increase the connectivity giving the client a wide range of options to fits all of his needs.
Specifications
| Computer | |
|---|---|
| CPU | ALLWINNER H5 CPU |
| DRAM | 512 DD3RAM |
| Storage | 8GB eMMC |
| SD SLOT | Micro SD Up to 64gb (not included) |
| RTC CHIP | DS3231 |
| Pre-installed OS | Ubuntu Core |
| Computer Interface | |
| Ethernet ports | 2 X ports 10/100 |
| Communication ports | 4 X customized serial ports on ordering: | RS485/RS232/RS422/Can BUS/2xAnalog inputs/2xAnalog outputs/2xDigital inputs / Digital outputs |
| USB ports | 1x mUSB |
| Digital Inputs | 10 x High speed digital inputs (24VDC) |
| Wi-Fi chip | MT7601UN |
| Serial signals | |
| RS232F | TX,RX,RTS,CTS,GND |
| RS232 | TX,RX,GND |
| RS485 | TX,RX,GND |
| RS422 | A,B,Y,Z |
| SPI CANBUS | CANH,CANL |
| UART CANBUS | CANH,CANL |
| Power Parameters | |
| Power supply options | 85-265 VAC /100-300 VDC | 10-48VAC / 10-60VDC | 25-60VAC / 36-72VDC | Direct input 5VDC/3A |
| Power connector | Phoenix Contact 4pins 3.5mm |
| Physical Characteristics | |
| Housing | Metal |
| Dimensions | 5.27(134)x5.27(134)x1.45(37) inch (mm) |
| Mounting system | Standard 35mm din rail / direct panel mounting / front panel mounting / 19” rack 1U |
