PMM0206 - Timing NTP

TIMING NTP - The true Network Time System

PMM0206 - Timing NTP

Price from USD 211.35

Key features

  • Many Software and Hardware options to fit your needs
  • Client/server architecture
  • Multi-protocol support
  • Network-wide deployment
  • 32-bit and 64-bit Windows support
  • Custom time zone and offset

Overview

DESCRIPTION

PMM Network Time Server provides a solution to system time maintenance problems. This powerful /server software enables you to set up a virtually fail-safe synchronized time environment for networks of any size and complexity, from small office networks (LAN) to those maintained at large enterprises (VPN, VLAN, WAN), from single site networks to those including numerous domains and involving complex routing techniques.

Network Time System allows the creation of a custom source of precise time in a corporate network environment establishing an interconnected time synchronization system for each and every machine and device on the network.

Network Time Server used for setting up and running a dedicated time server on the whole project network. The application is capable of time synchronization with external NTP/SNTP sources - public NTP time servers or local trusted time sources such as NMEA 0183 GPS receivers (via COM, USB, Bluetooth ports, TCP/IP, UDP multicasting), radio clock cards, NTP servers etc. Moreover, it can host the time received from an external time source for Windows workstations, any NTP/SNTP compatible devices and non-Windows NTP clients.

System Features

  • Client/server architecture
  • Set up your own single or multiple time servers capable of hosting and operating thousands of time clients (workstations or any NTP/SNTP compatible devices).

  • Multi-protocol support
  • Network Time System supports both its own proprietary time protocol and the world's most widely-used NTP/SNTP and NMEA 0183.

  • Network-wide deployment
  • Deploy Network Time System (Client) through Group Policy to all your Windows-based computers in just a few minutes.

  • 32-bit and 64-bit Windows support
  • Network Time System (Server) and (Client) are native 32 and 64-bit compiled executables. Both run as a system service and support all modern versions of Windows, from Windows 2003/XP to Windows 10/Server 2016.

  • Custom time zone and offset
  • Using this unique feature, customize the source time (for example, received from an NIST NTP Server) and distribute it to the time clients. Keep your time synchronized with UTC or convert it to the local time, add or deduct any number seconds/minutes/hours from the source time to have your own time offset.

    Specifications

    Ethernet Software Features
    ProtocolsModbus TCP
    Configuration OptionsWeb Console (HTTP/HTTPS), Telnet Console
    Time ManagementNTP Client
    Serial Software Features
    ProtocolsModbus RTU/ASCII
    Configuration OptionsSerial Console
    Computer
    CPU32-bit ARM core microcontroller
    Flash/SRAM512 KB/ 100 KB
    RTC CHIPDS3231
    Computer interface
    Ethernet1x 10/100
    USB Port1x USB2.0 type A
    Wi-Fi2.4/5GHz
    Serial Communication port1x RS485 (Fixed port) | 4x RS495-RS232
    Optional ModuleGSM Module
    SD Card Slot1x MicroSD
    Power Parameters
    Power Supply Options9-120 VDC | 85-285 VAC / 100-300 VDC
    Power ConnectorPhoenix Contact 4 pins 3.5mm
    Environmental Limits
    Operating Temperature-40 to 75oC (-40 to 167°F)
    Storage Temperature-40 to 85oC (-40 to 185°F)
    Humidity5 to 95% (non-condensing)
    Physical Characteristics
    HousingMetal
    Dimensions4 x 4 x 1.75 inch | 103 x 103 x 44 mm
    Mounting OptionsStandard 35mm DIN Rail | Direct Panel Mounting | Front Panel Mounting | 19” rack 1U
