PMM0620-032 - 32 x Digital Input 24VDC
32 x Digital Input 24VDC
Price from USD 128.50
Key features
- (16/32/64) x Isolated Digital Input 24VDC
- 32-bit ARM core microcontroller with 48 MHz clock
- Hot swap redundancy exchange and fail safe ready
- Stand alone programming or Modular operation modes
- 1x Serial RS485 port with power surge ±2.5kV isolation protection
- Overvoltage and reverse polarity protected
- Onboard Termination resistor via dip switch
- Wide range of power supply options (9-56 VDC)
- 5000V system/field isolation
- Simple to set up and cost effective
- High speed data reading with high reliability and accuracy
- EMI, EMS, EMC and shock protected
- -40 to 80 °C (-40 to 185°F) Operating temperature
- 5% to 90% Non-condensing Relative Humidity
- Standard 35mm din rail mounting bracket
Overview
PMM0620 is a reliable, and simple to set up digital Input module that has (16/32/64) isolated channels basically and can be extended to 64 channels.
Moreover, PMM0620 operates under three operational modes: Modular operation mode: the module is connected to a PLC by RS485 and implement specific function assigned by the PLC. Fail Safe mode: the module should be pre-programmed in case of lost connection with the PLC to carry on its function effectively. Stand-alone: the module can be programmed to work as PLC and control the field devices. In addition, PMM0620 industrial grade IO module can function under harsh environmental conditions of any site. It is reliable, easy to configure and has an extreme accuracy.
Specifications
| Interfaces | |
|---|---|
| Serial | 1x RS485 port |
| Ethernet | 1x 10/100 RJ45 |
| DI/DO | (16/32/64) x digital inputs 24VDC |
| USB | 1x USB2.0 Type micro-B |
| LED Indicators | 16x LED for Digital Input | 2x LED for communication |
| Power Parameters | |
| Input Power Supply Options | 9-56 VDC |
| Power Connector | Phoenix Contact 4 pins 3.5mm |
| Physical Characteristics | |
| Housing | Plastic |
| Dimensions | 3.91x4.37x0.99 inch (99.4x111.2x22.6 mm) |
| Mounting Options | DIN Rail |
