PMM0625XT - 16 x Isolated Transistor Digital Outputs, 80 VDC / 2 A per Channel
16 x Isolated Transistor Digital Outputs, 80 VDC / 2 A per Channel
Price from USD 52.00
Key features
- 16 Isolated transistor digital outputs
- 80 VDC / 2 A maximum load rating per channel
- Standard Modbus RTU communication over RS-485
- Designed for remote switching, control, and automation applications
- 32-bit ARM core microcontroller with 48 MHz clock
- Stand-alone operation or modular expansion capability
- Isolated RS-485 communication interface
- USB service port for configuration and maintenance
- Wide input power supply range (12 - 48 VDC)
- Overvoltage and reverse polarity protection
- Reliable industrial-grade design with surge protection
- EMI, EMS, EMC, and shock resistant
- Standard 35 mm DIN rail mounting
- Operating temperature: -40 to 80 °C (-40 to 185 °F)
- 5% to 90% non-condensing relative humidity
Overview
PMM0625XT is a 16-channel isolated transistor digital output module designed for industrial automation, remote control, and monitoring applications. The module provides sixteen transistor outputs that can be independently controlled through standard Modbus RTU communication over an RS-485 interface.
Each output channel is designed for DC switching applications with a maximum load rating of 80 VDC / 2 A per channel. The module is suitable for driving digital loads, signaling devices, external relays, control circuits, and other DC output applications where fast and reliable transistor switching is required.
Designed for reliable operation in harsh industrial environments, PMM0625XT combines isolated output channels, protected power input, isolated RS-485 communication, USB service/configuration access, and a wide 12 - 48 VDC power input range. Its compact DIN-rail mounting design makes it suitable for SCADA systems, PLC networks, renewable energy plants, substations, and general automation systems.
PMM0625XT is suitable for a wide range of industrial and utility automation applications, including:
Applications
- SCADA and remote terminal unit (RTU) systems
- Substation automation and control systems
- Solar and renewable energy plant control
- Remote alarm and annunciation systems
- DC digital load switching
- External relay and control circuit driving
- Industrial process automation
- General-purpose digital output expansion
Specifications
| Electrical Data | |
|---|---|
| Digital Outputs | 16 Isolated transistor digital outputs |
| Output Type | Transistor output |
| Control Method | Individually controlled digital output channels |
| Maximum Load Voltage | 80 VDC/channel |
| Maximum Load Current | 2 A/channel |
| Output Isolation | Isolated transistor output channels |
| Protection | Overvoltage and reverse polarity protection |
| Interfaces | |
| Serial Interface | 1x RS-485 port |
| Communication Protocol | Standard Modbus RTU |
| USB Interface | 1x USB service/configuration port |
| LED Indicators | 16x LED indicators for digital outputs | 2x LED indicators for communication status |
| Power Parameters | |
| Input Power Supply | 12 - 48 VDC |
| Power Connector | Phoenix Contact 4-pin, 3.5 mm terminal connector |
| Power Protection | Reverse polarity and overvoltage protection |
| Physical Characteristics | |
| Housing | Plastic enclosure |
| Dimensions | 103 × 103 × 22.5 mm | 4.05 × 4.05 × 0.88 inch |
| Mounting | Standard 35 mm DIN rail mounting |
| Environmental Conditions | |
| Operating Temperature | -40 to 80 °C (-40 to 185 °F) |
| Relative Humidity | 5% to 90% non-condensing |
