PMM0640 - Single Phase Energy Meter

Single Phase Energy Meter

Price from USD 347.12

Key features

• Simple to set up and cost effective
• Compatible with IEC 60687, EC 61036, IEC 61268, IEC 62053-21, IEC 62053-22, and IEC 62053-23 standards
• Hot swap redundancy exchange and fail safe ready
• Stand-alone programming or Modular operation modes
• The device supports Over the Air (OTA) programming through mobile application
• Active energy error percentage does not exceed 0.1% at 25°C
• Provides several power consumptions values such as active, reactive and apparent energy, voltage RMS, current RMS
• Digital power, phase, and RMS offset calibration programmable thresholds for line voltage SAG and overvoltage detections
• 32-bit ARM core microcontroller with 48 MHz clock
• 1x Ethernet 10/100 port
• 1x RS485 port
• 2x Relay output
• High resolution 0.91” OLED display
• Wide range of power supply options (10-60 VDC)
• Highly compacted size
• Simple to set up and cost effective
• Standard din rail mounting option
• -40 to 85 °C Operating temperature
• 5% to 90% Non-condensing Relative Humidity

Overview

PMM0640 is reliable, compact, and easy to setup single phase energy meter which is capable of computing energy consumption including active, reactive, apparent energy, and RMS calculations with extremely high accuracy and efficiency.

PMM0640 is programmed in advance to compute the energy consumption for field devices based on current values that are obtained from an external transformer and voltage values.

The energy measurements are displayed on a high- resolution OLED display allowing the client to monitor and observe the energy consumption. In addition, the client can update the controller’s settings configuration remotely through mobile application.

PMM0640 operates under three operational modes:

PMM0640 is compatible with several industrial standards such as: IEC 60687, IEC 61036, IEC 61268, IEC 62053-21, IEC 62053-22, and IEC 62053-23. Furthermore, it is designed to withstand the harsh environmental conditions.
