PMM0803 - DC-DC (85-265+10-60VDC)-(24v5A+ 5V4A) UPS
DC-DC (85-265+10-60VDC)-(24v5A+ 5V4A) UPS
Key features
- Two ultra-wide range input voltages: 10-60VDC and 85-256VDC
- Two outputs: 5V and 24V
- Input and output isolation withstand voltage 3000VDC
- High efficiency, conversion efficiency up to 88% (Typ)
- Output to charge 12V Battery
- 1x RS485 serial communication port
- Highly dependable, high quality, long-term efficient design, unstoppable work over 100000H
- Protection for both circuits as follow: System: reverse polarity / Overload / Input and Output Overvoltage Battery: Over-Charge / Over-Discharge
- 0.95" OLED Display
- Compact size with fan-less design
- Cooling by free air convection
- Wide range of mounting options
- Operating temperature: -40 to 85oC (-40 to 185°F)
- Ambient relative humidity: 5 to 95% (non-condensing)
- Serial port with power surge ±2.5kV isolation protection
Overview
DESCRIPTION
PMM0803 is a reliable and precise DC-DC converter with battery output.
It has two inputs which are 10-60v with 5V/4A output and 85-256VDC with 24V/5A output, all in the domain of two separate circuits to guarantee a continuous and unstoppable output outcome.
It features high efficiency; up to 88%, wide working temperature range -40~+85C and 3KVDC isolation voltage.
It uses an ATmega328 CPU along with an RS485 module for smooth communication along with any monitoring system.
PMM0803 follows a continuous-mode short circuit protection which comes with an over voltage and reverse polarity protection, it also contains a battery charging controller as well as BMS to protect the battery bank from overcharging and over-discharging.
This model has an added feature of a 0.95-inch OLED display that makes it easy and possible to monitor battery health and faults logs.
PMM0803’s power supply is excellent for the industrial environments with a harsh nature due to its high protection characteristics against high vibration, high dust, extremely low or high temperature.
Specifications
| Input characteristics | |
|---|---|
| Input voltage range | 10-60VDC |
| Maximum input voltage | ≤64 VDC |
| Reflected ripple current | 40mA (typical) |
| Impulse voltage (Isec.max） | -0.7 to 70VDC |
| Starting voltage | 9 VDC (MAX) |
| Start Time(Typ.) | 1mS (Nominal input voltage and constant resistance load) |
| Output characteristics | |
| Voltage regulation rate | ±0.5%（Tpy） |
| Load Regulation | ±1%（Tpy） |
| Start delay time | 100ms |
| Output voltage regulation | No adjustment |
| Output overcurrent protection | 110%-200%（Full voltage range input） |
| Output short circuit protection | Sustainable, self-healing |
| General specification | |
| Controller | ATmega328 |
| Serial Interface | 1x RS485 |
| Display | 0.95" OLED |
| Indicators | 2x LED For RS485 TX/RX | 2x LED For power status |
| Mechanical characteristics | |
| Housing | Metal |
| Dimensions | 3.93*3.93*1.7 inch (100*100*44 mm) |
| Mounting Options | Standard 35mm DIN Rail | Direct Panel Mounting | Front Panel Mounting | 19” rack 1U |
| Environmental conditions | |
| Operating temperature | -40 to +85℃ |
| storage temperature | -40 to +125℃ |
| Relative humidity | 5 to 95% (non-condensing) |
