PMM1008 - IO Mirror

Connects digital input to digital outputs

Key features

• Direct input-to-output signal communication over IP
• High-speed peer-to-peer I/O within 20 ms
• One physical alarm port for connectivity status
• Utility for quick and easy web-based settings
• Local alarm channel
• Remote alarm message
• Supports Modbus TCP for remote monitoring

Overview

PMM1008 is a cable-replacement solution that connects digital input signals to digital outputs over an IP network. It is equipped with 12 digital inputs, 12 digital outputs, and a 10/100Mbps Ethernet interface.

A pair of PMM1008 servers can connect remote sensor signals to a PLC controller, DCS systems, or a display device over Ethernet, eliminating the need to install additional signal wires. Up to 12 digital input signals can be connected from one PMM1008 to another with only 20 ms signal latency over a local area network.With the PMM1008, remote sensors can be connected to local controllers or display panels over copper, fiber, or wireless Ethernet infrastructures, and signals can be transmitted over virtually unlimited distances, without noise problems.

Specifications
